Professional production and manufacturing of industrial doors
More than ten years of experience in the production and manufacturing of industrial doors
Garbage discharge door
Category：
Product
Keywords：
Product
Production Process
Garbage discharge door is mainly used at the bottom of the garbage treatment equipment, and is responsible for uninstalling the garbage. They control through hydraulic or electric controls, which can be turned on and closed as needed to ensure the normal operation of garbage treatment equipment and improve the efficiency and safety of garbage treatment. The design and material selection of the garbage removal door take into account the special requirements of the garbage treatment environment, such as corrosion resistance, service life and safety, to ensure efficient and safely handling garbage.
Special design in the rails to reduce the friction with the curtain in the case of wind pressure. Drive device uses a specific motor of the company to ensure the smooth operation of the door and the longer service life.
Product parameters
|
material structure |
Door body: Use the middle steel skeleton double -faced 4mm thick steel plate with a total thickness of 108mm. The color can be sprayed as required
|
|
Skeleton: Using 100mm thick steel skeleton
|
|
|
sealed system |
It can effectively partition the smell produced by garbage |
|
Control method |
Local control: located on the local switch box on the side of the unloading door, the protection level is IP55 |
|
centralized control concentrated control cabinet and display table of the garbage crane control room, the protection level is IP55 |
|
|
induction switch: You can use infrared, radar or geomagnetic induction switch
|
|
|
Installation location |
outdoor installation : suitable for outdoor environment |
Equipment
The company has advanced equipment: 6-meter optical fiber cutting machine, 6-meter large bending machine, automatic slitting shearing machine, robot welding, hard shutter board fully automatic assembly line, automatic cloth cutting machine, continuous heat sealing machine, aluminum profile extrusion machine, fully automatic spraying assembly line, etc.
