Fast stacking door
Category：
Product
Keywords：
Product
Production Process
In modern society, with the acceleration of urbanization, people's pace of life is becoming faster and faster. In such an environment, people's demand for convenience and safety in life is also increasing. As a modern intelligent access control device, the rapid stacking door is born at the right time.
Rapid stacking door, as the name suggests, is a door that can be opened and closed quickly, usually used for vehicle entrances and exits or places where frequent entry and exit are required. Its characteristics are fast opening and closing speed, high safety, and convenient maintenance. This type of door is usually composed of a series of door panels that can be quickly stacked together to form a complete door body.
Rapid stacking door has the following main characteristics:
1. Fast opening and closing speed: The rapid stacking door adopts advanced electric drive technology, which can achieve an opening and closing speed of seconds, greatly improving the passing efficiency of vehicles and personnel.
2. High safety: The rapid stacking door takes safety factors into consideration when designing, and is equipped with multiple safety protection devices, such as infrared sensors, anti-collision strips, etc., to ensure that the door body will not cause harm to vehicles and pedestrians during operation.
3. Energy saving and environmental protection: The rapid stacking door adopts energy-saving materials. The door body can effectively isolate the indoor and outdoor temperatures when opening and closing, which plays a role in heat preservation and energy saving.
4. Convenient maintenance: The design of the rapid stacking door takes into account easy maintenance. The door body adopts a modular design. When repairing, only the damaged module needs to be replaced, which is convenient and fast.
Product parameters
|
Scope of application |
outer departments (increasing wind resistance effects in inside the curtain) |
|
Open speed |
0.8-1.5m/s (adjustable), high frequency opening (1000 times/day) |
|
Safety device |
Infrared protection device under the door frame (the car's vehicle does not fall through the door) |
|
Seal performance |
The curtain area is equipped with an aggravated air barrier, which can be seamless with various uneven grounds. (Anti -insect -proof dust and sound insulation) |
|
door body structure |
The door frame is 2.0mm galvanized steel plate |
|
Curtain color |
orange red, gray, blue, yellow |
|
appearance |
door frame. |
|
Control voltage |
Safe low pressure 24VDC |
|
curtain materials |
High -density PVC base cloth, thickness of 0.9mm, color can be customized |
|
stretch strength |
5700/5100N/5cm, tearing strength 900/800N/5cm |
|
fire prevention level |
German standard MZD/NBL difficulty |
|
Use temperature |
-10 ℃ -70 ℃/ultra-cold-resistant area -40 ℃ |
|
transparent window |
Import PVC transparent crystal soft board, 1.5mm |
|
wind anti -wind material |
wind -resistant steel wind tube |
|
wind resistance |
25m/s50pa |
Equipment
The company has advanced equipment: 6-meter optical fiber cutting machine, 6-meter large bending machine, automatic slitting shearing machine, robot welding, hard shutter board fully automatic assembly line, automatic cloth cutting machine, continuous heat sealing machine, aluminum profile extrusion machine, fully automatic spraying assembly line, etc.
